Pp Hose Nipples (Flange End Type )

About Pp Hose Nipples (Flange End Type )

Pp Hose Nipples  (Flange End Type )

PP HOSE NIPPLES

Available M.O.C.:

• PP (Polypropylene),
•


Flange Drilled:

• ANSI B 16.5 (150 Class)
• BS 10 Table D
• BS 10 Table E
• BS 10 Table F
• DIN STD

SIZE		CODE
IN	MM
1" X 3/4 "	32 X 25	P1HNF01
1" X 1"	32 X 32	P1HNF02
1 1/2" X 1"	50 X 32	P1HNF03
1 1/2" X 1 1/4"	50 X 40	P1HNF04
1 1/2" X 1 1/2"	50 X 50	P1HNF05
2" X 1"	63 X 32	P1HNF06
2" X 1 1/4"	63 X 40	P1HNF07
2" X 1 1/2"	63 X 50	P1HNF08
2' X 2"	63 X 63	P1HNF09
3" X 1 1/2'	90 X 50	P1HNF10
3" X 2"	90 X 63	P1HNF11
3" X 3"	90 X 90	P1HNF12
4" X 2"	110 X 63	P1HNF13
4" X 3"	110 X 90	P1HNF14
4" X 4"	110 X 100	P1HNF15

AS PER IS : 8008 -1976 (PART VII)

MAX.WORKING PRESSURE 10 Kg/cm 2

Adherence to International Standards

Our PP Hose Nipples (Flange End Type) strictly follow DIN standards, guaranteeing assured compatibility and reliability in diverse industrial setups. The manufacturing precision with a tolerance of +/- 2 mm assures consistent performance for critical applications, minimizing the risk of connection failures or leaks.


Versatility and Application Range

Suitable for use with various piping and hose systems, these hose nipples are employed in fluid transfer, chemical processing, and water management. Their adaptability in thickness, length, and diameter enables seamless integration with existing infrastructure, making them an efficient solution for industrial exporters and suppliers.
